- Safety: legs locked in position on the bearing using the central nut . No risk for the puller to escape from the bearing.
- Shear pin: the pin shears if torque limit is exceeded. Supplied with 2 spare pins.
- Set of 3 spare pins. U.306-24J3.
-
Fitted with the anti-rotation b ush U.20-12. The button protects the screw when a bar is used to block p uller rotation.
- Adaptable puller accessory: slide hammer U.2.
|
|
- C mini - maxi [mm] 25 - 260
- L x l x H [mm] 125 x 325 x 370
- P maxi [mm] 220
- T [kN] 70
- Legs U.20BSE4
- Screw Size U.20-B1S< li>Hex Size [mm] 24
- Ton [t] 7
- Screw Size [mm] 24
- [kg] 4 ,300
|
-
