- Combines color, haze, and clarity measurement
- Saves cost vs buying separate tools
- Great for comprehensive optical QC
|
- Large display with clarity/haze metrics
- Multiple optical readings
- User-friendly operation
|
- Light sources for haze/transmittance: CIE-A, CIE-C, CIE-D65
- Standards : ASTM D1003/D1044, ISO13468, JIS K 7105/7361/7136, GB/T 2410, CIE No.15, ISO7724-1, ASTM E1164, DIN5033, JIS Z8722 Condition C.
- Measurement parameters: Haze, transmittance (T%), clarity (C%), spectral transmittance, color spaces (CIE-Lab, LCh, Luv, XYZ, Yxy), Hunter Lab, Munsell, CMYK, whiteness/yellowness, tint, chromatic indices, plus Pt-Co, Gardner, etc.
- Wavelength range: 400–700 nm
- Wavelength interval: 10 nm
- Geometry: 0/d
- Aperture sizes: 18 mm / 25.4 mm
- Haze resolution: 0.01 %
- Haze repeatability: ≤ 0.05 % (haze < 10 %); ≤ 0.1 % (haze ≥ 10 %)
- Sample thickness: ≤ 145 mm
|
-
