- High measurement accuracy and consistency.
- Improved light intake and spectral resolution.
- Versatility in lighting & modes.
- Fast measurement & stability
- Robust calibration & compensation
|
- Dual optical path design: Employs a differential spectrum engine and dual optical paths for more stable performance and reduced measurement error.
- Multiple standard illuminants & indices: Supports up to ~37 standard light sources and 40+ measurement indices (color, transmission, reflectance, etc.).
- Switchable aperture recognition: Automatically recognizes and switches among multiple sample apertures (e.g. XLAV, LAV, MAV, SAV).
- Android touch interface & display: Comes with a 7-inch capacitive touch screen and Android OS for intuitive use.
- Fluorescence / UV calibration & brightness correction: Has built-in algorithms to adjust UV intensity and restore real color in very dark samples.
- Automatic temperature & humidity compensation: To maintain measurement stability when ambient conditions change.
- PCI / software compatibility: Supports output and data transfer via USB, PC software (Color Expert) for data storage and color matching.
|
- Wavelength Range : 360 nm – 780 nm.
- Measurement Interval (Wavelength Step) : 10 nm
- Spectral Metho : Concave grating + differential spectrum engine
- Repeatability : ΔE*ab ≤ 0.005 for DS-37D.
- Inter-instrument Agreement : ΔE*ab ≤ 0.12 between instruments.
- Measurement Time : < 2 seconds in single mode.
- Integrating Sphere Diameter : 152 mm
- Light Sources : Pulsed xenon lamp + LED
- Display : 7-inch capacitive touch screen, Android OS
|
-
