Precision ground and lapped to a specific thickness. |
- Advanced heat treatment technology for Mitutoyo steel blocks achieve s excelent abrasion resistance and minimizes any change in length over t ime.
- Enable user to achive optimum flatness and surface finish needed for gauge block and thus maximize the
|
- Hardness: 800 HV
- Flexural strength by 3 point bending: 1960 Mpa
- Young’s Modulus x 10-4 : 20.6 MPa
- Poisson’s ratio: 0.3
- Specific gravity: 7.8
- Thermal conductivity: 54.4 W/m. k
- Content: 1, 1.25, 1.5, 2, 3, 5, 10, 15, 20, 25
mm
|
-
Warranty Part: 12 Month(s)
-
Services: 12 Month(s)
|
