- High accuracy and reliable melting point determination for pharmaceutical and chemical laboratories
- Improved observation of melting process through real-time video and image recording
- Higher testing efficiency by analyzing up to four samples simultaneously
- Enhanced data traceability and compliance with regulatory standards such as FDA 21 CFR Part 11
- User-friendly operation thanks to the large touchscreen and Android operating system
- Efficient laboratory data management with large internal storage and export functions
- Suitable for colored or difficult samples that conventional melting point testers may struggle to analyze
|
- Automatic video melting point detection system
- Real-time video monitoring of sample melting process
- Simultaneous testing of up to 4 samples in one batch
- High-resolution camera with video recording and replay function
- 8-inch Android-based capacitive touch screen interface
- Advanced data storage and export capability
- Multi-user ID management with permission control
- Temperature curve display for better observation of phase transition
- Connectivity for printer and data transfer (USB, RS232, Wi-Fi, RJ45)
- Compliant with pharmaceutical and laboratory standards (GLP, GMP, FDA 21 CFR Part 11)
|
- Position Capacity: 4 samples simultaneously
- Temperature Range: Room temperature – 400 °C
- Temperature Resolution: 0.1 °C
- Temperature Accuracy: ±0.4 °C (<200 °C); ±0.7 °C (<300 °C)
- Temperature Repeatability: 0.2 °C
- Temperature Gradient: 0.1 °C – 20 °C/min step-less adjustment
- Magnification of Lens: 8x
- Display: 8-inch capacitive touch screen
- Storage Capacity: 128 GB ROM
- Method Storage: Up to 200 methods
- Graphic Storage: Up to 500 records
- User ID Management: Up to 100 users
- Communication Ports: USB ×3, RS232, Wi-Fi, RJ45
|
-
