- Versatility: can read plates from 6 up to 384 wells and also supports cuvette measurements.
- Broad application: supports assays for nucleic acids, proteins, ELISA, microbial growth, cytotoxicity, spectral scanning, etc.
- High throughput & speed: fast kinetic readings (e.g. 96 wells in < 8 seconds) reduce experiment time.
- Integrated temperature control (up to 65 °C) and condensation management enable temperature-sensitive assays.
- Shaking functions (linear, orbital, double orbital) for mixing within wells, enhancing assay uniformity.
- Software support with intuitive PC software and modes like endpoint, kinetic, spectral scanning, and “well area scan.”
- Compliance and audit readiness: supports features like audit trail, user management, electronic signatures, and data integrity checks (checksum) consistent with regulatory standards (e.g. 21 CFR Part 11) via PC software “Secure”.
|
- Quantitative analysis of nucleic acids and proteins, ELISA, and microbial growth experiments are possible by selecting a wavelength in the range of 200 – 999 nm
- Various workflows can be applied by providing endpoint, kinetic, spectral scanning, and well area scanning modes.
- Compatible with 6 to 384 well plates.
- Quantitative analysis of nucleic acids without dilution using the Micro-Volume Plates accessory.
- Temperature-controlled down to 65°C and control of water vapor condensation to perform temperature-sensitive assays.
- Linear, orbital and double orbital shaking.
- Measurement possible through Cuvette port (Optional) (to be released in the second half of 21st).
|
- Light source: Xenon flash lamp, which allows fast pulsed illumination for absorbance measurements.
- Detector: photodiode array for rapid spectroscopic data acquisition.
- Wavelength range: 200 – 999 nm with 1 nm increments.
- Bandwidth: ~ 2.9 nm.
- Dynamic range: 0 to 4.0 OD.
- Resolution: 0.0001 OD.
- Wavelength accuracy: ±1 nm.
- Wavelength repeatability: ±0.2 nm.
- OD accuracy: <1% at 2.0 OD, <3% at 2.5 OD.
- OD linearity: <1% deviation from 0 to 2.5 OD.
- OD repeatability: <0.5% at 2.0 OD.
- Stray light: 0.03% at 230 nm.
- Kinetic read speed: for 96 wells, < 8 seconds.
|
-
