- Efficient menu operation on the console with single knob navigation.
- Wheel measurement accuracy can be maximized with this tool because there is no physical contact in the measurement.
- Spa ce saving design allow this machine to be installed close to a wall and maximizes shop space.
|
-
|
Dimension (W x H x D) : 1346 x 1816 x 832 mm
Weight : 141 Kg (311 lbs.)
Power Requirement : 196-256V, 3 amp, 50/60 Hz, 1 ph
Capacity of Rim Width : 1.5 – 20 in. (38 – 508 mm)
Capacity of Rim Diameter : 10 – 30 in. (254 – 762 mm)
Capacity of ALU : 7.5 – 38 in. (191 – 965 mm)
Max. Tire Diameter : 38 in. (965 mm)
Max. Tire Width : 20 in. (508 mm )
Max. Tire Weight : 135 lbs. (61 kg)
Imbalance resoulution : ± 0.05 o z (1.0 g)
Placement accuracy : 512 positions, ± 0.35°
Balancing spee d : 150 rpm
Motor : Programmable drive system and DC motor |
-
Warranty Part: -
-
Services: 12 Month(s)
|
