- After sales service
- Warranty of parts
|
- Pedal for braking system
- Tailstok sleeve and handwheel with adjustable precission scale
- DRO (Digital Read Out) for prevent common error
|
- Main Motor (kW / V / Ph): 2.2 / 380 / 3
- Max. Swing Over Bed (mm): 370
- Max. Swing Over Cross Slide (mm): 220
- Max. Swing in Gap (mm): 505
- Distance Between Center (mm): 1000
- Bed Width (mm): 189
- Inch Thread (TPI): 4 – 56
- Metric Thread (mm): 0.4 – 7
- Tool shank (mm): 16 x 16
- Taper of Tailstock: MT4
- Dimension (mm): 1880 x 640 x 1360
- Net Weight / Gross Weight (kg): 550 / 650
|
-
Warranty Part: 12 Month(s)
-
Services: 12 Month(s)
|
