- Silent design 70dB @7m
- Easy to start
- Ready to connect with ATS
|
- Panel Digital with COMAP AMF20
- Power full diesel engine
- B uilt-in AMF system
|
- Stand by Output (kVA/kW) : 11.8 / 9.5 (1PH) – 18.7/23.3 (3PH)
- P rime Output (kVA/kW) : 9.5 / 7.6 (1PH) – 15/18.7 (3PH)
- Voltage (V) : 230 / 400
- Frequency (Hz :) 50
- Phase : 1 / 3
- Rated Current (A) : 43.1 / 22
- Rated Speed Current
(rpm):1500
- Tank Capacity (L): 9 6
- Recommended Prime Running Time (hr):8
- Consumption Fuel Full Load (L/hr):3.7
- Noise Level (at 7m) (db):70
- Start System:12V electric< li>Power Factor (cos Theta): 0.8
- Engine Model : 4DW81-23D
- Engine T ype :
4 cylinders, in-lined,
- 4 stroke,
- water cooled
- Oil Type : SHELL RIMULA R4X
- Volume Engine (cc) : 2270
- Capacity of Cooling W ater (L):8.5
- Fuel:Diesel (Solar)
- Oil Capacity (L): 7.8
|
-
Warranty Part: 06 Month(s)
-
Services: 12 Month(s)
|
