- Low rotary speed of air end, smooth running with stability and silen t operation
- All electric components are european brand schneider magn etic contactor
- Adopt big rotor for low rotary speed of air end, smoot h running with stability and silent
operation
- Zero current startup, low energy consumption, no impact to power grid caused by peak current< li>2 Centrifugal fan with thermostatic control
- Digital Control Panel
- Pre filter and after filter to remove moisture and other particle th at may
carry over from the process
- Automatic time-control drain sys tem designed to automatically drainage / remove water from air filter an d air dryer
- Stainless-steel Tubing
- High efficiency air dryer (Equi valent to 10035966)
|
- Variable Speed Drive by Schneider
- IPM motor (Internal Permanent M agnetic motor drive screw compressor)
- Direct drive, no gear box or be lts
|
- Motor Power : 15 Kw / 20 HP
- Air Delivery : 2200 L/min, 132m3/h, 7 8 c.f.m
- Working Pressure : 10 bar, 145 psi
- Tank Capacity : 500 L < li>Noise Level : 65 dB(A)
- Connection output : 1 inch
|
-
Warranty Part: 12 Month(s)
-
Services: 12 Month(s)
|
