- Powerful electro magnet provides enough holding force for the toughe st applications
- Compact size makes it easy to handle
- Accurate dril ling of up to 50mm in diameter into steel sections
- Can using for tapp ing process with tapping attachment
|
- Equipped 4 speed mechanical gear box
- Equipped coolant tank
- Equ ipped safety chain
- Equipped chip guard
|
- DiaxDepth of Core Drill (mm) : 75 x 50
- DiaxDepth of Twist Drill B it (with Drill Chuck) (mm) : 16 x 110
- DiaxDepth of MT3 Tapper Shank D rill (Cold) (mm) : 32 x 150
- DiaxDepth of Tap (with Optional MT3 Tappi ng Chuck (Warm) (mm) : 25.4 x 40
-
Motor (kW / V / Ph) : 1.8/220/50< li>No. Load Speed :
- Speed 1 (rpm) : 90 / 150
- Speed 2 (rpm) : 120 / 200
- Speed 3 (rpm) : 180 / 300
- Speed 4 (rpm) : 230 / 380
- Magnet ic Adhesion (N) : 3200
- Dimension LxWxH (cm) : 30x25x52
- Weight (Kg ) : 25
|
-
Warranty Part: 06 Month(s)
-
Services: 03 Month(s)
|
